Compound Planetary Inline Spiral Bevel (SBT)
Compound Planetary Inline Spiral Bevel (SBT) gearmotors combine our Inline Planetary (IL) and Spiral Bevel (SB) gear reducers to offer a greater variety of speed reduction than either gearbox alone. Compact and highly efficient, SBT gear motors are ideal for high ratio, high power applications
Compact and highly efficient. The IL gear reducer mounts directly off the motor shaft. The IL shaft then feeds into the SB gear reducer housed in a unique tubular casing. The tubular housing features smooth, easily cleanable surfaces. (SBT) gearmotor with a 5HP HAZARDOUS LOCATION (XP) Our patented Hazardous Duty/Explosion Proof (XP) motors are ideally suited for processing applications requiring strict sanitation and washdown tolerance in combination with safety concerns arising from hazardous liquids, vapors and or dust.
Combining our Sanifan Technology motor, an IL series planetary reducer, and spiral bevel final output stage yields an exceptionally sanitary and efficient package. The SBT tubular housing features smooth, easily cleanable surfaces and can be supplied as flange mounted, face mounted or foot mounted. Large bore hollow shafts are easily accommodated, making these ideal for “piggyback” scraper/agitator mixer drives. An internal oil pump assures proper bearing lubrication in any orientation, at any speed. The pump is bi-directional, meaning proper performance is assured regardless of output rotation direction and is maintenance free.
These units make excellent retrofit candidates for existing unsanitary cast iron gearmotor drives and SMI engineers will partner with you to ensure a “drop on” retrofit success.
The IL gear reducer mounts directly off of the motor shaft. The IL shaft then feeds into the SB gear reducer housed in a unique tubular casing. The tubular housing features smooth, easily cleanable surfaces and is often equipped with a flange or C-face mounting.
The SBT output shaft is at right angle to the motor shaft and is available as solid or hollow bore with either a vertical or horizontal orientation. SBT units are made to order allowing OEMs and end users to specify a particular mounting configuration for the best possible integration with new or existing equipment.
